Cutting Type

Diameter(mm)

Steel core(mm)

Segment Dimension(mm)

Segment Number

 Arbor(mm)

Brick, Concrete, Reinforced Concrete, Asphalt

Dia 300

2.2

40X3.2X10/12

22

20, 22.23, 25.4, 35, 50, 60

Dia 350

2.2

40X3.2X10/12

25

Dia 400

2.6

40X3.6X10/12

28

Dia 450

3

40X4.0X10/12

32

Dia 500

3

40X4.0X10/12

36

Dia 550

3.6

40X4.6X10/12

40

Dia 600

3.6

40X4.6X10/12

42

Dia 650

4

40X5.0X10/12

46

Dia 700

4

40X5.0X10/12

50

Dia 750

4

40X5.0X10/12

54

Dia 800

4.5

40X5.5X10/12

57

Dia 850

4.5

40X5.5X10/12

58

Dia 900

5

24x7.0/6.2x10/12

64

Dia 1000

5

24x7.0/6.2x10/12

70

Dia 1200

5.5

24x7.4/6.6x10/12

80

Dia 1400

6

24x8.0/7.2x10/12

92

Dia 1600

7.2

24x9.2/8.4x10/12

108

Both laser welding and silver welding are available, other size are available upon requested.
